The ANSI Globe Valve is a type of valve designed for regulating fluid flow in a piping system, adhering to the standards set by the American National Standards Institute (ANSI). Known for its reliability and versatility, the globe valve is widely used in various industrial applications, including oil and gas, water treatment, power generation, and chemical processing. Its unique design allows for precise flow control and is suitable for both on-off and throttling service.

Features

• Meet design ANSI B16.5, B16.34, B16.10,B16.25 (for NPS≤24), MSS SP-44(for NPS>24), API-600
• Straight and Y patteren body design
• OS & Y,outside screw and yoke
• BB,Bolted bonnet
• Yoke intergral with bonnet
• Rising stem and handwheel
• Loose disc,choice of plug or ball
• Renewable seat ring or Body seat ring
• Impact handwheel for 10" & above
• Horizontal servece
• Flanged or buttwelding ends
• Normal Size: 2"~20"
• Pressure: 150LB~2500LB
• Connection: Flanges,RTJ Flange,Butt Weld,Groove
• Material:Carbon Steel, Forged Steel
• Carbon Steel: ASTM A105, ASTM A216 WCB, ASTM A217 WC6, ASTM A217 WC9, ASTM A217 C5, ASTM A217 C12, ASTM A217 C12A
• Stainless Steel: ASTM A351 CF8, ASTM A351 CF8M, ASTM A351 CF3, ASTM A351 CF3M, ASTM A351 CM8, ASTM A890 GR4A, ASTM A890
• Operate: Handwheel, Wormgear, Gearbox, Penumatic Actuator, Electric  Actuator, Hydraulic Actuator.

Standards:

• Steel Globe Design: API 600 / BS1873
• Steel Valves: ASME B16.34
• Face to Face according to: ASME B16.10
• Flanges Ends according to: ASME B16.5
• Butt Welding Ends according to: ASME B16.25
• Inspection and Testing according to: API 598 / API 6D
